Tamaya digital planimeters are excellent tools to use when measuring irregular-shaped areas on plans or drawings.
They eliminate the need for grids, charts, or calculations done by hand.

PLANIX 5 and PLANIX 6 measure area in actual square centimeters or square inches. Area shown in plan or drawing must be calculated from this value.

PLANIX 7 with numeric keyboard allows user input of scale so area from plan or drawing can be computed.

PLANIX 5(polar planimeter) is attached to a weighted base by an arm that allows movement within a circular area.

PLANIX 6 and PLANIX 7 (roller planimeters) are attached to wheels that allow unlimited horizontal travel and vertical travel within the limits of the arm movement.

PLANIX EX / PLANIX 5/6/7 (3.65M)

You can obtain a free viewer by following this link

PLANIX 5

PLANIX 6

PLANIX 7

Models	PLANIX 5	PLANIX 6	PLANIX 7
Power	Internal NiCd or AC adaptor
Operating hours	After 15 hours recharge : 30 hours
Display method	LCD with zero suppression
Resolution	One digit corresponds to 0.1cm2 or 0.01 in.2
Accuracy	Better than +/- 0.2% (+/- 2/1000 pulses)
Display capacity	8 digits output/input, HOLD, MEMO, BATT E, READY, cm2, in2
	--	--	SCALE, m2, km2, ft2, acre
Measuring range	35.6cm dia. 14" dia.	300cm x 30cm 118" x 11.8"
Weight	Approx. 900g	Approx. 650g
Dimension (Polar arm length)	64 x 213 x 39mm (222mm)	150 x 240 x 39mm
Carrying case	183 x 260 x 64 mm

△=Option	PLANIX 5	PLANIX 6	PLANIX 7	PLANIX　10S "Marble"	PLANIX EX	PLANIX EX-L
X, Y coordinates	*	*	*	*	○	○
External outputs	*	*	*	*	○	○
Area	○	○	○	○	○	○
Side length	*	*	*	○	○	○
Line length	*	*	*	○	○	○
Radius	*	*	*	*	○	○
Center point	*	*	*	*	○	○
Triangle (base length, height and area)	*	*	*	*	○	○
Angle (side length and angle)	*	*	*	*	○	○
Scale: key input	*	*	○	○	○	○
Scale: PLOT-real measurement correction	*	*	*	○	○	○
Measuring area for differing scale of X, Y	*	*	Area only	Area only	○	○
Sum and average measurement	○	○	○	○	○	○
Decimal point set-up	*	*	*	○	○	○
Auto power off	○	○	○	○	○	○
Calculation	*	*	*	*	○	○
Display	dot LCD 8 digits x 1 line			dot LCD 16 digits x 2 lines	dot LCD 17 digits x 3 lines
Measuring range	300mm x 300mm	300mm x 3m		300mm x 10m	380mm x 10m	450mm x 10m
Minimum line reading	± 0.1cm			± 0.05mm
Accuracy	± 0.2%			± 0.1%
Auto close function	*	*	*	○	○	○
Automatic numbering	*	*	*	*	△	△
Printer	*	*	*	*	△	△
RS-232C interface cable	*	*	*	*	△	△
